Technical data
Series LP110
Technical data
- control Siemens CNC
- generating spindle adapters:
- KK 3 – H 28 – horizontal
- D 28 – H 28 – horizontal
- D 20 L – V 28 – vertical
- work spindle bore: Ø 30 mm
- feed rate X- and Z-axis: up to 700 mm/min
- rapid travel speeds X- and Z-axis: 15 m/min
- travel X-axis, radially: 300 mm
- travel Z-axis, axially: 280 mm
- generating spindle speed: up to 6000 rpm
- rotary positioning accuracy of the main spindle: 0,01°
- workpiece spindle torque: 35 Nm
- tool spindle torque: 7 Nm, optional 16 Nm
- total power: 20 KW, 30 A
- standard voltage: 400 V, 50 Hz – or on request
- pneumatic power: 5–8 bar
- hydraulic power: 20 bar
- dimensions (L × W × H)
2,800 × 1,450 × 2,000 mm
weight: approx. 3,500 kg (7800 LBS) – depending on the equipment
